6.5 Inch G065VN01 V2 AUO LCD Panel 640x480 VGA Signal Input LCD Controller Board

Product Categories
N&S ELECTRONIC CO., LIMITED
Contact Now

6.5 Inch G065VN01 V2 AUO LCD Panel 640x480 VGA Signal Input LCD Controller Board

Brand Name : AUO LCD Panel

Model Number : G065VN01 V2

Certification : CE

Place of Origin : SHANGHAI

MOQ : 1

Price : usd

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000

Delivery Time : 24hours

Packaging Details : standard packing

Model : G065VN01 V2

Resolution : 320(RGB)×240 , QVGA

Contrast Ratio : 800:1 (Typ.)

Brightness : 340 cd/m² (Typ.)

Signal Interface : LVDS (1 ch, 6-bit)

Contact Now

6.5 Inch G065VN01 V2 AUO LCD Panel 640x480 VGA Signal Input LCD Controller Board

AUO G057VN01 V2 Basic Information

Panel Model : G065VN01 V2
Panel Type : a-Si TFT-LCD , LCM
Panel Size : 6.5 inch
Resolution : 640(RGB)×480 , VGA
Display Mode : TN, Normally White, Transmissive
Active Area : 132.48×99.36 mm
Outline : 153×118×11.2 mm
Surface : Glare (Haze 0%), Hard coating (3H), Antireflection
Brightness : 800 cd/m² (Typ.)
Contrast Ratio : 600:1 (Typ.)
Display Colors : 262K/16.2M (6-bit / 6-bit + FRC) , CIE1931 55%
Response Time : 15/10 (Typ.)(Tr/Td)

6.5", 640×480, 6/8-bit, LVDS, 2D, WLED, HB, Flat, LCM Hot Model

Panel Model Size Type Resolution cd/m2
G065VN01 V2 6.5" LCM 640×480 800
NL6448BC20-30D 6.5" LCM 640×480 550
NL6448BC20-21C 6.5" LCM 640×480 800
NL6448BC20-21D 6.5" LCM 640×480 550
AA065VE01 6.5" LCM 640×480 700
NL6448BC20-30 6.5" LCM 640×480 600
NL6448BC20-30JF 6.5" LCM 640×480 950
T-55629D065J-LW-A-AAN 6.5" LCM 640×480 700

6.5 Inch G065VN01 V2 AUO LCD Panel 640x480 VGA Signal Input LCD Controller Board6.5 Inch G065VN01 V2 AUO LCD Panel 640x480 VGA Signal Input LCD Controller Board6.5 Inch G065VN01 V2 AUO LCD Panel 640x480 VGA Signal Input LCD Controller Board
